Logisys 550W 20+4-pin ATX Power Supply w/SATA
PCIe
Large 120mm Ball Bearing Cooling Fan for Quiet Performance (Black)

Logisys 550W 20+4-pin ATX Power Supply w/SATA, PCIe, Large 120mm Ball Bearing Cooling Fan for Quiet Performance (Black)

26,40 $

Logisys 550W 20+4-pin ATX Power Supply w/SATA, PCIe, Large 120mm Ball Bearing Cooling Fan for Quiet Performance (Black)

Out of stock

Description

Logisys 550W 20+4-pin ATX Power Supply w/SATA, PCIe, Large 120mm Ball Bearing Cooling Fan for Quiet Performance (Black)
Condition New Unit Dimensions Are 10.25×7.5×5 inches
26.0×19.1×12.7 cm
The Warranty Period Is 1 Year Each Unit Weighs 3.15 lbs / 1.43 kg
Packaging Retail Box Each Master Box Has 10 Units
Product Number PS550J12BK Master Box Dims Are 25.75×21.5×8.5 inches
65.4×54.6×21.6 cm
Tech Support By Dealer Each Master Box Weighs 33.4 lbs / 15.15 kg
Support Contact — Each Pallet Has 180 Units
Regulatory Approval CE Each Pallet Weighs 617 lbs / 279.87 kg
Country of Origin China



Logisys 550W 20+4-pin ATX Power Supply
Features/Specifications:
  • Logisys 550W 20+4-pin ATX Power Supply
  • General Features:
  • Color: Black
  • 550-watt maximum power output
  • 120mm ball bearing fan
  • 115V – 230V switchable
  • Black sleeved wires
  • One (1) 16-inch 20+4-pin ATX power connector
  • One (1) 12V 4+4-pin connector
  • One (1) 6-pin PCI Express power connector
  • Three (3) large Molex 4-pin power connectors
  • One (1) small floppy power connector
  • Three (3) SATA power connectors
  • Over Voltage protection
  • Over Power protection
  • Short Circuit Protection
  • 100% Hi-pot & Function (Chroma) tested
  • 100% Burn-in under high Ambient Temperature (50°C)
  • Low Noise and Ripple
  • Energy Star Efficiency
  • Windows 7 compatible
  • AC Input:
  • 100 – 120Vac, 10A, 200 – 240Vac, 5A
  • Frequency: 50/60Hz
  • DC Output:
  • +3.3V, 30A
  • +5V, 38A
  • +12V, 25A
  • -12V, 0.8A
  • +5VSB, 2A
  • Unit Dimensions:
  • 3.5 x 5.8 x 5.5-inches (H x W x D, approximate)
  • Regulatory Approvals:
  • CE
  • CB
  • BSMI
  • C-Tick
  • Fimko
  • Demko
  • Nemko
  • Semko
Package Includes:
  • Logisys 550W 20+4-pin ATX Power Supply
  • Power cord
Additional Information:
  • Notes:
  • P/N: PS550J12BK
  • EAN: 8 626260 035327
  • Product Requirements:
  • Available power outlet
  • ATX case
  • ATX motherboard

Additional information

Weight 1,43 kg
Dimensions 26,0 × 19,1 × 12,7 cm
Product Condition

Part Number
