Logisys PS550E12 550W 20+4-pin ATX Power Supply w/SATA & Large 120mm Ball Bearing Cooling Fan for Quiet Performance

Logisys PS550E12 550W 20+4-pin ATX Power Supply w/SATA & Large 120mm Ball Bearing Cooling Fan for Quiet Performance

Call for pricing

Logisys PS550E12 550W 20+4-pin ATX Power Supply w/SATA & Large 120mm Ball Bearing Cooling Fan for Quiet Performance

Description

Logisys PS550E12 550W 20+4-pin ATX Power Supply w/SATA & Large 120mm Ball Bearing Cooling Fan for Quiet Performance
Condition
Refurbished



 Unit Dimensions Are 8.5×6.5×3.75 inches
21.6×16.5×9.5 cm
The Warranty Period Is 90 Days  Each Unit Weighs 2.85 lbs / 1.29 kg
Packaging Retail Box  Each Master Box Has 10 Units
Product Number PS550E12-R Master Box Dims Are 19.75x18x7.5 inches
50.2×45.7×19.1 cm
Tech Support By Dealer  Each Master Box Weighs 31 lbs / 14.06 kg
Support Contact — Each Pallet Has 320 Units
Regulatory Approval FCC, CE, UL  Each Pallet Weighs 962 lbs / 436.36 kg
Country of Origin China



Logisys 550W ATX Power Supply

  Features/Specifications:


  • Logisys 550W ATX Power Supply

  • General Features:
  • 20/24 pin ATX connector
  • 550-watt power supply
  • Large 120 mm ball bearing fan for quiet performance (75 CFM / 2000 RPM)
  • One (1) 12-inch ATX power connector
  • One (1) 12-inch 12V ATX power connector
  • Two (2) 12-inch SATA power connector
  • Four (4) 12-inch 4-pin large Molex power connectors
  • One (1) 12-inch 4-pin small floppy power connector
  • Supports Intel Pentium 4 and AMD motherboards
  • Low noise and ripple
  • Short circuit and over-voltage protection
  • Thermal overload cut-off protection

  • Power Specifications:
  • 110 – 250V switchable power supply (100-120 VAC, 10A; 200-240 VAC, 5A)
  • +3.3V / 30A
  • +5V / 38A
  • +12V / 25A
  • -12V / 0.8A
  • -5V / 0.5A
  • +5 Vsb / 2A

  • Unit Dimensions:
  • 3.25 x 6 x 5.5-inches (H x W x D, approximate)

  • Regulatory Approvals:
  • FCC
  • CE
  • UL
  • CSA
  • Semko
  • Demko
  • Nemko
  • Femko
  • C-Tick
  • BSMI
  • TUV
  Package Includes:


  • Logisys 550-watt ATX power supply
  • Power cord
  Additional Information:


  • Notes:
  • Model: PS550E12
  • UPC: 8 62626 00156 5

  • Product Requirements:
  • ATX case
  • ATX motherboard
  • Available power outlet

Additional information

Weight 1,29 kg
Dimensions 21,6 × 16,5 × 9,5 cm
